Cold rolled 200 series stainless steel strip 2B bA finish
Type 316L(UNS 31635) is a Titanium stabilized austenitic chromium-nickel stainless steel containing molybdenum. This addition increases corrosion resistance, improves resistance to pitting chloride ion solutions and provide increased strength at elevated temperatures. Properties are similar to those of type 316 except that 316Ti due to its Titanium addition can be used at elevated sensitisation temperatures. Corrosion resistance is improved, particularly against sulfuric, hydrochloric, acetic, formic and tartaric acids, acid sulfates and alkaline chlorides.
Used in Food Industries, Chemical Industries , Electrielcal Industries, Genrater Industries, Shaft Industries, Cement Industries, Gas Industries, Power Project etc..
Stainless Steel 316L Strip Specification
| Item | Stainless Steel 316L Strip(Hot rolled, cold rolled) |
| Standard | JIS, AISI, ASTM, GB, DIN, EN, etc |
| Surface | the surface and finish of stainless steel 316L Strip:
2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand
blast, Brush, etching, etc |
| Thickness | 0.3~10.0mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Package | Standard export package, suit for all kinds of transport, or as
required. |
| Export to | India, Indonesia Malaysia, Singapore, Saudi Arabia, Qatar, UAE, Iran, Iraq, Oman, South Africa, Nigeria, Kenya, Italy, UK, Brazil, Russia , Egypt , Kuwait , Taiwan, Australia . |
| STANDARD | UNS | JIS | WERKSTOFF NR. | AFNOR | BS | GOST | EN |
| SS 316L | S31603 | SUS 316L | 1.4404 | Z7CND17‐11‐02 | 316S11/316S13 | - | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Stainless Steel 316L Strip Useful Information
316L Stainless Steel Strip Chemical Properties :
| | C | Mn | Si | P | S | Cr | Mo | Ni | N |
316L
(S31603) | 0.03
max | 2.0
max | 0.75
max | 0.045
max | 0.03
max | min: 16.0
max: 18.0 | min: 2.0
max: 3.0 | min: 10.0
max: 14.0 | 0.10
max |
316L Stainless Steel Strip Mechanical Properties :
| Grade | Tensile Strength
ksi (min) | Yield Strength
0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness
(Rockwell B) MAX |
316L
(S31603) | 70 | 25 | 40 | 217 | 95 |
316L Stainless Steel Strip Physical Properties :
| |
Density
lbm/in3 | Thermal Conductivity
(BTU/h ft. °F) | Electrical
Resistivity
(in x 10-6) | Modulus of
Elasticity
(psi x 106 | Coefficient of
Thermal Expansion
(in/in)/°F x 10-6 | Specific Heat
(BTU/lb/°F) | Melting
Range (°F) |
| 0.29 at 68°F | 100.8 at 68 212°F | 29.1 at 68°F | 29 | 8.9 at 32 – 212°F | 0.108 at 68°F | 2500 to 2550 |
| | | | | 9.7 at 32 – 1000°F | 0.116 at 200°F | |
| | | | | 11.1 at 32 – 1500°F | | |
316L Stainless Steel Strip Application
- 316L Stainless Steel Strip Used for Architectural trim and molding
- 316L Stainless Steel Strip Used for Construction material in large buildings
- 316L Stainless Steel Strip Used for Kitchen benches, sinks, troughs, equipment, and appliances
- 316L Stainless Steel Strip Used for Chemical containers, including for transport
- 316L Stainless Steel Strip Used for Automotive and aerospace structural
- 316L Stainless Steel Strip Used for Food processing equipment, particularly in beer brewing, milk processing, and wine making
- 316L Stainless Steel Strip Used for Heat exchangers
- 316L Stainless Steel Strip Used for Woven or welded screens for mining, quarrying & water filtration
- 316L Stainless Steel Strip Used for Nuts, bolts, screws, and other fasteners in the marine environment
- 316L Stainless Steel Strip Used for Dyeing industry
Production Process
Packing and delivery
If you have any question, please contact us any time.
